 SWG 3016/32 Series Wireless Gateway
AKOM-SWG
CASQ
Specifications
SWG-3016  Series Wireless Gateway
Product Name SWG-3016G SWG-3016L  SWG-3032G SWG-3032L
Module Type GSM LTE GSM LTE

Module Number

Channel Number
 India India
 LTE FDD: B1/B3/B5/B8 LTE FDD: B1/B3/B5/B8
LTE TDD: B38/B39/B40/B41 Europe/Middle East/Africa/ LTE TD D: B38/B39/B40/B41 Europe/Middle East/Africa/
WCDMA: B1/B8 Korea/Thailand  WCDMA: B1/B 8 Korea/Thailand
TD-SCDMA: B34/B39  LTE FDD: B1/B3/B5/B7/B8/B20 TD-SCDMA: B34/B 39 LTE FDD: B1/B3/B5/B7/B8/B20
CDMA: BC0  LTE TDD: B38/B40/B41 CDMA: BC0  LTE TDD: B38/B40/B41
GSM: 850/900/ GSM: 900/1800MHz  WCDMA: B1/B5/B8 GSM: 850/900/ GSM : 900/1800MHz  WCDMA: B1/B5/B8
Band 1800/1900MHz Australia/New Zealand/Taiwan  1800/1900MHz Australia/Ne w Zealand/Taiwan
  GSM: B3/B8 GSM: B3/B8/Lain America /Lain America
North America  North America
LTE FDD: B1/B2/B3/B4/B5/B7 LTE FDD: B1/B2/B3/B4/B5/B7
LTE FDD: B2/B4/B5/B12/B13/  LTE FDD: B2/B4/B5/B12/B13/
/B8/B28 B14/B66/B71 /B 8/B28 B14/B66/B71
LTE TDD: B40 WCDMA: B2/B4/B5 LTE TD D: B40 WCDMA: B2/B4/B5
WCDMA: B1/B2/B4/B5/B8 WCDMA: B1/B2/B4/B5/B8

GSM: B2/B3/B5/B8  GSM: B2/B3/B5/B8

Weight (with packaging) 2.84kg 3.44kg 3.8kg 4.4kg

Power 25W 36W
Dimension (bare) 440mm*45mm*22 0mm
Dimension (with packaging) 510mm*90m m*350mm

SIM Card Hot-Swap

LAN 1* 10/100M

WAN 1*  10/100M
USB Micro-B 1 (Supports  USB M icro-B storage)

Console 1

Operaion Temperature 0℃ ~ 45℃
Operaion Humidity Range 10% ~ 90%
Storage Temperature Range -20℃ ~ 70℃
