Proportion-Air
Mass Flow Controllers
Proportion-Air manufactures complete ranged of electro-
Pneumatic flow pressure  and flow control valves that have
quick response and the ability to control flow rates from 2
SCFH to 250 SCFM.
These flow control valves are industrial quality and can be
mounted in any orientation with the ability to withstand
intense vibrations while continuing to control flow. Our
flow control assemblies are subject to a 10:1 turndown
ratio (inquire about 20:1) meaning that we will control flow
at 10% to 100% of the range with ±0.25% repeatability.
The gases we can control include Air, Argon, Carbon
Dioxide, Helium (not bubble tight), Nitrous Oxide, Nitrogen
and Oxygen.
FQPV2 | F- FQB3 | F- FQB2 | F-
Series Series Series
< 1 SCFM Flow < 30 SCFM Flow < 250 SCFM Flow
Control Control Control
F-Series
Mass Flow Transducer
FCV
1″ Flow Control Valve
The building block for all our mass flow controllers is
the F-series mass flow transducer. The F-series uses
high speed differential pressure technology to
produce an electrical signal proportional to the mass
flow of air – or whatever gas you want to control.
This high-speed flow signal can be used by a wide
variety of Proportion-Air mass flow control valves to
close the loop directly around air flow.
Based on your required flow rate, the F-series mass
flow transducer is matched to the appropriate flow
control valve and then calibrated specifically to your
exact flow range.
