The Havells LED Linear Highbay is a powerful and energy-efficient lighting solution designed to replace traditional 400W Metal Halide and fluorescent fixtures, delivering up to 54,000 lumens of bright, uniform light. Engineered for warehouses, industrial facilities, retail centers, gyms, and sports arenas, it combines durability with performance, offering a lifespan of 50,000 hours and reducing maintenance costs. With wattage and color temperature options (3000K/4000K/5000K), 0-10V dimming, and easy integration of occupancy sensors, it provides flexibility and smart control for any application. Certified by ETL and DLC for quality and efficiency, the Linear Highbay is built to withstand demanding environments, operating reliably in temperatures from -20°C to +45°C. Backed by a 5-year warranty, it ensures long-term value, making it the ideal choice for businesses looking to enhance lighting performance while cutting energy costs.

Category Business

Comments

                     Havells LED Linear Highbay – Power, Performance & Efficiency
                     Catalog#
HL Project:Fixture Type: Date:
LINEAR HIGHBAY Note:
Hit the Tab key or mouse over the page to see all interactive elements.
The Havells LED Linear Highbay is an energy-efficient replacement for
400W Metal Halide or T8 fluorescent tubes, offering up to 50,000 hours of
maintenance-free use. Its durable, shatter-resistant design prevents hot
spots and discoloration over time. Perfect for warehouses, garages, retail
stores, and sports facilities. It delivers reliable, uniform lighting with no
bulbs to replace. Moreover, you can now add sensors to them without any
installation hassle and wiring issues. Just remove the knob on the highbay
and mount the sensor in place of that.
FEATURES & BENEFITS
Delivers high efficacy in 400W light providing upto 54,000 lumens.

Dimming capabilities for optimal customization.
ETL listed, DLC certified, suitable for dry and damp location use.
Operating Temperature:-20°C to +45°C
Selectable
Rated for 50,000 hours, offering a 5-year warranty. Wattage* Selectable *Color
3000K | 4000K | 5000K CCT IP 20
Model Number Wattage Lumens
HL-LHB-MW-MCCT-115W 85W/100W/115W 11475lm/13500lm/15525lm
HL-LHB-MW-MCCT-150W 120W/135W/150W 16200lm/18225lm/20250lm
HL-LHB-MW-MCCT-180W 140W/160W/180W 18900lm/21600lm/24300lm
HL-LHB-MW-MCCT-240W 200W/220W/240W 27000lm/29700lm/32400lm
HL-LHB-300W5K 300W 40500lm
HL-LHB-400W5K 400W 54000lm
HL-LHB-300W5K-HV 300W 40500lm
HL-LHB-400W5K-HV 400W 54000lm
MCCT models codes feature selectable CCT options: 3000K/4000K/5000K
PRODUCT SUMMARY
Efficacy Dimming
135 lm/W 0-10V Standard
CCT Options Operating Temp.
3000K / 4000K / 5000K -20℃ to +45℃ OPTIONAL ACCESSORY
CRI Warranty
≥80 5 Years Emergency Battery Backup and Occupancy Sensor.
Beam Angle Finish
120° White
Input Voltage Mounting
120-277Vac | 277-480Vac Suspended and Ceiling APPLICATIONS
Power Factor (PF) Housing Material
0.95 Metal Powder Coated Warehouse & Storage, Industrial Facilities, Sports Facilities
THD Lens Type    & Gyms, Manufacturing Facilities, and Retail Centers.
≤10% Clear Diffuser
Default Parameters DLC PRODUCT INFORMATION
Wattage CCT Order ID DLC Model Number DLC Source Identifier Classification
115W 5000K HL-LHB-MW-MCCT-115W LINEAR HB SUS X 115W SWSC S-7N6B6Z Premium
150W 5000K HL-LHB-MW-MCCT-150W LINEAR HB SUS X 150W SWSC S-SXZXW9 Listed
180W 5000K HL-LHB-MW-MCCT-180W LINEAR HB SUS X 180W SWSC S-JMYKGR Premium
240W 5000K HL-LHB-MW-MCCT-240W LINEAR HB SUS X 240W SWSC S-MFHLHT Listed
300W 5000K HL-LHB-300W5K LINEAR HB SUS X 300W 850 S-HJN206 Listed
400W 5000K HL-LHB-400W5K LINEAR HB SUS X 400W 850 S-65S9BT Listed
300W 5000K HL-LHB-300W5K-HV LINEAR HB SUS X 300W 850 HV S-5WFPY3 Listed
400W 5000K HL-LHB-400W5K-HV LINEAR HB SUS X 400W 850 HV S-Y7R8YR Listed
1 www.havellsLighting.com [email protected] 855-428-3557
© Havells Lighting LLC | All Rights Reserved.
Specifications and Data Subject to change without Notice.
PERFORMANCE
3000K (≥80 CRI) 4000K (≥80 CRI) 5000K (≥80 CRI)
Model Number Wattages Input Current Lumens Efficacy Lumens Efficacy Lumens Efficacy
HL-LHB-MW-MCCT-115W 85W/100W/115W 0.746A/0.877A/1.008A 11475lm 135 lm/W 13500lm 135 lm/W 15525lm 135 lm/W
HL-LHB-MW-MCCT-150W 120W/135W/150W 1.053A/1.184A/1.316A 16200lm 135 lm/W 18225lm 135 lm/W 20250lm 135 lm/W
HL-LHB-MW-MCCT-180W 140W/160W/180W 1.228A/1.404A/1.579A 18900lm 135 lm/W 21600lm 135 lm/W 24300lm 135 lm/W
HL-LHB-MW-MCCT-240W 200W/220W/240W 1.754A/1.929A/2.105A 27000lm 135 lm/W 29700lm 135 lm/W 32400lm 135 lm/W
*Lumen and efficacy data are based on the CCT of each higher wattage SKU*.
Model Number Wattages System Lumens CCT Input Current Efficacy Input Voltage
HL-LHB-300W5K 300W 40500lm 5000K 2.631A 135 lm/W 120-277Vac
HL-LHB-400W5K 400W 54000lm 5000K 3.508A 135 lm/W 120-277Vac
HL-LHB-300W5K-HV 300W 40500lm 5000K 1.140A 135 lm/W 277-480Vac
HL-LHB-400W5K-HV 400W 54000lm 5000K 1.520A 135 lm/W 277-480Vac
PACKAGING DETAILS
Product  Case Case  Net Weight Gross Weight with Pallet
Model No. Dimesion (LxWxH) Qty (units) Dimension (in) Product (lbs) Packaging (lbs) Load
HL-LHB-MW-MCCT-115W 19.0x13x1.8 2 21.1x6.0x15.2 7.50 17.0 50
HL-LHB-MW-MCCT-150W 24.8x13x1.8 2 32.7x6.0x15.2 8.10 19.0 34
HL-LHB-MW-MCCT-180W 30.8x13x1.8 2 32.7x6.0x15.2 9.50 21.8 30
HL-LHB-MW-MCCT-240W 30.8x13x1.8 2 32.7x6.0x15.2 9.50 21.8 30
HL-LHB-300W5K 36.2x13x1.8 2 38.3x6.0x15.2 12.6 28.4 30
HL-LHB-400W5K 45.5x13x1.8 2 47.5x6.0x15.2 14.8 33.5 24
HL-LHB-300W5K-HV 36.2x13x1.8 2 38.3x6.0x15.2 9.90 23.0 30
HL-LHB-400W5K-HV 45.5x13x1.8 2 47.5x6.0x15.2 13.0 30.0 24
ACCESSORIES
Emergency Occupancy
Battery Backup Sensor
(HL-ANT-6-4R)
www.havellsLighting.com [email protected] 855-428-3557 © Havells Lighting LLC | All Rights Reserved.2 Specifications and Data Subject to change without Notice.
DIMENSIONS
SELECTABLE WATTAGE & CCT: 115W SELECTABLE WATTAGE & CCT: 150W SELECTABLE WATTAGE & CCT: 180W
Length (L) Width (W) Height (H) Length (L) Width (W) Height (H) Length (L) Width (W) Height (H)
19.0 inch 13 Inch 1.8 Inch 24.8 inch 13 Inch 1.8 Inch 30.8 inch 13 Inch 1.8 Inch
SELECTABLE WATTAGE & CCT: 240W WATTAGE: 300W-5K/300W-HV WATTAGE: 400W-5K/400W-HV
Length (L) Width (W) Height (H) Length (L) Width (W) Height (H) Length (L) Width (W) Height (H)
30.8 inch 13 Inch 1.8 Inch 36.2 inch 13 Inch 1.8 Inch 45.5 inch 13 Inch 1.8 Inch
Photometric Result
HLSSLH030625V10
Last Updated: Sep 09, 2025 11:00 AM
www.havellsLighting.com [email protected] 855-428-3557 © Havells Lighting LLC | All Rights Reserved.3 Specifications and Data Subject to change without Notice.
