Electric Vehicle Battery Supplier in India

 How are we?
We are in the business of Manufacturing, Research
and development (R&D) & trading of EV batteries
& Solar batteries, EV kits, Stepper Motors & Step
Servo Motors, 3D Printers, Automation parts, IOT,
Drone items incl. DIY kits & ready to fly drones.
We believe in 360 Deg approach for our clients to
provide hassle free platform for all our services
and products.
Our client includes but not limited to IIT- Madars,
IIT Kanpur, GNFC, ISRO,DRDO, various Govt.
organizations, etc.
2
content
Types of electric vehicles
EV Hybrid Vehicle
Regenerative  Controller
Li ion Battery pack mfg process
3
Types of electric vehicles
Battery Operated Electric Vehicle (BEV or
EV)
Hybrid Electric Vehicle (HEV)
Plug-in Hybrid Electric Vehicle (PHEV)
Range Extension Electric Vehicles (REx)
Fuel Cell Electric Vehicles (FCEVs)
4
Battery Operated Electric Vehicle (BEV or EV)
As the name suggests these vehicles are fully
operated through power generated from a
battery (Li-ion).
This type of vehicle does not come with the
traditional combustion engine and thus emits
zero carbon monoxide or pollutants in the
atmosphere.
Examples of BEVs: Tesla
Model 3, BMW i3, Hyundai
ioniq, Ford Focus, etc.
5
Hybrid Electric Vehicle (HEV)
This vehicle features both the conventional combustion
engine & battery-powered electric motor. But the battery
cannot be charged by plugging in through an electricity
input/ charging station, instead, it captures energy while
braking and batteries are charged.
Examples of
HEVs: Volvo
XC90, Toyota
Prius
6
Plug-in Hybrid Electric Vehicle (PHEV)
  type of EV category from its name. Unlike hybrid vehicles,
PHEVs battery can be charged through a plug-in socket as
well as power generated through braking and the car
operates on the both combustion engine and electric
powered motor. Benefits of PHEVs are the ability to cover
shorter distances without using the combustion engine and
increased range from fuel, battery charging & regenerative
braking.
Examples of  PHEVs:
BMW i8, Toyota Prius
Prime
7
Range Extension Types of Electric Vehicles (REx)
This type of vehicle features both combustion engine &
electric motor but most of the driving is done by the electric
motor only. The internal combustion engine is only there to
charge the battery if in case it gets low during a journey.
Example of REx: BMW i3
8
Fuel Cell Electric Vehicles (FCEVs)
This type of vehicle stores hydrogen gas in the tank & use
electric motors like BEV. A fuel cell combines hydrogen with
oxygen present in the air & generates electricity which
powers the electric motor.
Like the BEVs, it does not contain tailpipe and the byproduct
is only water. There is no need to plug-in as the fuel cells are
recharged by refilling the hydrogen.
Hydrogen infrastructure is far from reality as of now, which
is not the case with Charging infrastructure as it has gained
worldwide momentum.
Example of FCEV: Toyota FCV
concept
9
What is a EV Hybrid Vehicle
Hybrid electric vehicles are powered by an internal
gasoline-powered motor and one or more electric motors
to power it.
Hybrid cars are designed to switch between using
gasoline and electric power or using both at the same
time, depending on what’s most efficient at the moment.
Hybrids come in different types, including those that can
be plugged in to charge their batteries and others that
just recharge by running the engine or through braking
It’s called Regenerative.
10
   Which car is better, EV or hybrid?
If one has a spare gas powered car than going
for an EV is a good idea as once you the hit
highway for a long drive the range anxiety will
kick in. If one can have only one car than as
far as today is concerned getting a hybrid
makes more sense.
11
     what is full and half hybrid
Half hybrids have an electric motor that
assists the gas engine, but always needs the
gas engine running for it to assist.
Full” hybrids have an electric motor that can
move the car without the gas engine running,
though only with electricity that originally
comes from the gas engine
12


        Series-parallel hybrid vehicle
parallel hybrid vehicle Series hybrid vehicle
13
        Parallel Hybrid Vehicle
In a PHEV, mechanical and electrical powers are both connected to the
driveline, as shown in Figure  In the case of parallel architectures, good
performance during acceleration is possible because of the combined
power  from both engines .
. Different control strategies are used in a preferred approach. If the power
required by the transmission is higher than the output power of the ICE,
the electric motor is turned on so that both engines can supply power to
the transmission. If the power required by the transmission is less than the
output power of the ICE, the remaining power is used to charge the battery
packs . Moreover, mechanical and electric power could be decoupled, and
the system has a high operating flexibility enabling three modes of
operation: purely combustion; purely electric and hybrid. Usually, a PHEVs
are managed in purely electric mode at low speeds, until the battery
charge state reaches a predetermined low threshold, typically 30%.
14

   Series hybrid electric vehicles (SHEVs)
Series hybrid electric vehicles (SHEVs) involve an internal
combustion engine (ICE), generator, battery packs, capacitors
and electric motors . SHEVs have no mechanical connections
between the ICE and the wheels. The ICE is turned off when the
battery packs feed the system in urban driving. A significant
amount of energy is supplied from the regenerative braking
The series hybrid configuration is mostly used in heavy
vehicles, military vehicles, and buses . An advantage of this
topology is that the ICE can be turned off when the vehicle is
driving in a zero-emission zone. Moreover, the ICE and the
electric machine are not mechanically coupled;
15
       hybrid two wheeler Part’s
BIKE Kit 17 Inch Scooter Kit 10 Inch
16
                 Bill of Material
1. BLDC Motor
2. Regenerative  Controller
3. Throttle
4. DC-DC converter
5. Li ion battery pack
6. Charger
7. fasteners and tools
17
         Regenerative  Controller
When the vehicle is running, the controller
supplies the electrical energy from the battery
to the motor. When the driver presses the
brake pedal, the controller stops the electric
energy supply to the motor and starts
charging from generator to battery.
18
        Regenerative Braking System
A regenerative Braking System is a braking system that generates
electrical energy during braking action. This generated energy is used
for charging the battery, which is used again to rotate the motor (to
run the vehicle).
Working principle:
This regenerative braking system works on the principle of
‘conservation of energy’. The principle says that, the energy converts
from one form to another form.
In friction braking system, the kinetic energy of the wheel is converted
into the heat energy, which is lost to the atmosphere.
But in regenerative system, the kinetic energy of wheels is converted
into the electrical energy.
This system is mostly used in electric or hybrid vehicles, which uses a
motor to run the vehicle.
19
20


              Li ion battery pack
Parts Required:
1. 18650 Battery ( ROBOCRAFT )
2. BMS (ROBOCRAFT)
3. Ni Strips (ROBOCRAFT)
4. Battery Level Indicator  (ROBOCRAFT)
5. 18650 Battery Holder (ROBOCRAFT)
6. KAPTON Tape
7. SPOT Welding Kit
8.EPOXY
21
